Engineering Execution: Pipeline Transportation System For Liquid Hydrocarbon And Other Liquids (ASME B31.4) Gas Transmission And Distribution Piping Systems (ASME B31.8)

INSTRUCTOR : HILMAN AHMAD & ASSOCIATES

Held On : 11 - 14 December 2018, In Jakarta

what is this ?

The products carried in liquid or gases pipelines include a wide range of materials. Crude oil or gases systems gather production from onshore and offshore fields, while transmission lines transport crude or gases to terminals, interconnection points, and refineries. The fluids may be of domestic origin or imported. Refined petroleum product, including gasoline, aviation fuels, kerosene, diesel fuel, heating oil, and various fuel oils, are sizable portions of the pipelines business, whether produced in domestic refineries or imported to coastal terminals. Other materials include petrochemical feedstock (also known as secondary feedstock) such as benzene, styrene, propylene, and aromatics such as xylene, toluene, and cumene that are delivered by pipeline from refineries to petrochemical production plants or to other refineries. Also carried by pipeline are liquefied petroleum fuels such as liquefied natural gas (LNG) (short distances), liquefied petroleum gas (LPG) and propane, all of which are gases at standard temperature and pressure. Still other materials transported by pipelines include carbon dioxide and anhydrous ammonia, both transported as liquids under their own pressure. In recent years, long-distance pipelines have been constructed to carry distillate fractions from the distillation of crude oils from refineries to production facilities for crude feedstock such as bitumen recovered from tar sands and heavy oils. Such feedstock are too viscous to be transported by pipeline. However, the distillate fractions are used to dilute these feedstock, with the resulting mixture being suitable for delivery back to the refinery by pipeline for further processing. Also in recent years, long-distance pipelines have been constructed to carry “produced water” from oil and gas fields to refineries and other industrial facilities that use copious amounts of water, but are located in areas or areas where water availability is limited.

what you get it ?

• To IDENTIFY the design, cause, and impact pipeline and associated equipment
• To PROVIDE a framework for pipeline design and execution
• To DESCRIBE the role and structure of the pipeline sizing staging and procedures effectives and efficient.
• To IDENTIFY the international code and standart transmission pipeline

WHAT BENEFIT ?

The objective of this course are :

1. Participants know and having capability to identification and execute Pipeline Sizing and Engineering Management,
2. Participants know and solving case study on Pipeline Engineering and Execution Management,
3. Participants have capability to describing and designing Pipeline

WHO IS THE INSTRUCTOR ?

Hilman Ahmad & Associates is an independent consultant in mining, and oil & gas industry, who manage the Education Center for Professionals. The Director himself has been practicing production operation, safety, and corrosion control engineering in Indonesia for more than twenty-five years. He post-graduated from Tokyo Institute of Technology (sponsored by UNESCO) in 1977. He joined in-field-practice program at Nippon Kokan Steel Company & Research Center Kawasaki, Japan, for production facility, design & construction, and corrosion prevention & control in 1983, and collaborated with Cormon Industrial Research Center, Brighton, UK, for integrity on-line corrosion monitoring development in 2000. He has been delivering consultative course in production operation, maintenance, safety, pipeline (onshore and offshore) and corrosion control for personnel from oil, gas, & mining company and petrochemical industry since 1979.

WHEN AND WHERE ?

Training scheduled on 11 – 14 December 2018, 08.00 – 16.00 (Jakarta Time).

Training will conduct on Pomelotel Hotel, Jalan Dukuh Patra Raya No.28, Kuningan, RT. 11/RW.1, Menteng Dalam, Jakarta Selatan 12870.

HOW TO REGISTERATION ?

Registration for participants via Mr. Arfi Yesso, Badan Kejuruan Mesin – PII, email : bkmesin_pii@yahoo.co.id and arfi.yesso@gmail.com, phone : 021 31904667 or 081316716412.

HOW MUCH THE INVESTMENT ?

Fee for every participant is Rp 8.000.000,- (non-member PII) or Rp 7.500.000,- (member PII), with facility soft-file and hard-file (training material), lunch, certificate, snacks.

WHAT KIND THE SCHEDULE ?

	TIME	INSTRUCTORS
DAY 01, Tuesday 11 December 2018
THE BASICS OF PIPELINE SYSTEM	08.00 – 16.00 bbwi	Hilman Ahmad
PIPELINE CODES AND STANDARDS
Pipeline Transportation (ASME B31.4)
Gas Transportation (ASME B31.8)
CASES STUDY
DAY 02, Wednesday 12 December 2018
EGINEERING DESIGN & MATERIAL SELECTION	08.00 – 16.00 bbwi	Hilman Ahmad
CONSTRUCTION AND INSTALLATION
CASES STUDY (OFFSHORE and ONSHORE)
DAY 03, Thursday 13 December 2018
OPERATIONS AND MAINTENANCE	08.00 – 16.00 bbwi	Hilman Ahmad
CASES STUDY
DAY 04, Friday 14 December 2018
CORROSIONS AND PIPELINE INTEGRITY	08.00 – 11.00 bbwi	Hilman Ahmad
CASES STUDY

2 Days Professional Training: Project Cost Estimation Quality Management EPC Energy, Power Plant, and Industry (PMBOK, AACE, APIQ1)

Dilaksanakan pada 24 - 25 November 2018, di Hotel Aksana, Padang, Sumbar

 “Training ini memiliki Nilai Wajib PKB bagi pemegang Sertifikasi Insinyur Profesional”



Outline

Project Cost and Estimation merupakan bagian penting dalam sebuah project eksekusi, hal ini ditandai dengan dilakukannya sejak awal proyek sampai di akhir proyek. Di awal proyek menentukan metode atau cara dalam penanganan proyek – proyek yang berjalan. Di akhir project menentukan tingkat profitabilitas dan jasa produksi.

Project Cost and Estimation tidak hanya sekedar menghitung dan menentukan harga barang, namun lebih dari itu juga melakukan estimasi pekerjaan – pekerjaan yang menentukan dalam project eksekusi. Sebagian besar kurang atau malah tidak disadari bahwa cost dan Estimator sangat menentukan keberhasilan sebuah project dijalankan dan memberikan nilai keuntungan signifikan.

Cost estimation terpenting adalah mengetahui dan mengerti sequence dari Engineering, seluk -beluk Procurement, dan Resources Loading Construction. Seorang estimator harus meliputi segala aspek di Engineering, misalnya CTR, kemudian kalkulasi forwarding dan supply chain untuk di procurement, dan tentunya equipment loading saat konstruksi. Estimasi juga mencakup overhead, project management, dan sunk cost lainnya.

Training ini akan memberikan gambaran menyeluruh tentang dunia Cost and Estimation dari sisi yang lain. Sebuah perhitungan cost and estimation yang tidak hanya menghitung atau mengkalkulasi sesuai dengan time schedule, keterlibatan resources, namun juga safey dan risk management. Sebuah training professional beyond rules of thumbs, namun juga perhitungan actual di lapangan.

Materi Secara Singkat

Hari – 1

Membahas tentang segala cost aktifitas yang selalu digunakan untuk Engineering, Procurement, Construction, dimana point – point tersebut adalah bagian terpenting untuk menghitung direct cost. Materi detail sebagaiberikut :

1.    Scope of Work

Project management definitions

Project management initiation

2.    Work Breakdown Structures (WBS)

Project scope and arrangements

Project Structuring and breakdown

3.    Project Scheduling

Project critical path

Project resources allocation

Project planning

4.    Resources Plan

Optimization resources planning

5.    Risk Registering

Risk Identification

Risk interface

6.    Organizational Project Management

Engineer allocation

Construction labor allocation

7.    Work Method (Onshore – Offshore)

Case study work method onshore

Case study work method offshore

8.    Fabrication Delivery

Hari - 2

Membahas lebih dalam cost and estimation eksekusi disertai dengan studi kasus di beberapa paket project : petrochemical, mining, infrastructure, oil and gas, power plant, etc. yang ditemukan banyak sekali over budget. Dimulai dengan pembahasan Facilities, Wages, dan Managements.Materi detail sebagai berikut :

1.    Cost and Estimates Tools

Expert judgments

Input project cost and estimation

Estimating Philosophy

2.    Facilitates Estimation

Case study on facilitations matters

3.    Overhead Estimation

Case study on overhead matters

4.    Wage Estimation

Man-hours

Cost, Time, Resources

5.    Management Estimations

6.    Surveying

Early works : surveying

7.    Risk Quantities

Risk identifies

8.    Interface Quantities

Interface effects

Interface Root Caused

Instruktur

Ir. Muhammad Ade Irfan, MBA., IPM.

Alumnus Teknik Perkapalan ITS dan Magister Management UGM Jogjakarta, pernah bergabung dengan beberapa perusahaan besar untuk konstruksi dan project. Diantaranya PT. Waskita Karya (Persero) tbk., kemudian bergabung dengan PT. Raga Perkasa Ekaguna dengan posisi sebagai Estimation Manager untuk beberapa paket pekerjaan di onshore maupun di offshore. Beberapa project besar yang pernah ditangani diantaranya adalah :EPCI North Duri Development – 13(onshore) Project 2011, Chevron Pacific Indonesia, Call Out Construction Services 2012, durasi 5 tahun, BP Berau Ltd.EPCI Surface Facilities Pondok Makmur (onshore) 2013, PT. Pertamina EP., EPCI Onshore Receiving Facility 2012, Petronas Carigali (Ketapang) Ltd.EPCI Mila – Asti Pipeline and Platforms Development (offshore) 2012, CNOOC SES Ltd., EPCI NUI Development (offshore) 2012, PHE ONWJ., EPCI -1 Services, PHE-12, PHE-24, CPP-2 include pipeline (offshore) 2014, PHE WMO., Technical Framework Contract (3 years) paket offshore 2013, PHE ONWJ., Ethylene-2 Capacity Expansion Project, PT. Chandra Asri (2015) danEvonikSumiAsih (2013).

Selain itu juga menjadi Expert Consultant Cost and Estimation lingkupFEED dan Detail Design Engineering oleh PT. Pertamina (Persero) seperti FEED Offshore Pipeline Semarang 2014, FEED Offshore CBM di Medan 2015, Belawan. Ruang lingkup yang dikerjakan meliputi FEED, Detail Design, MTO, dan Estimation untuk penentuan Owner Estimate dan tender – tender EPCI.

PESERTA

Training cost and estimation merupakan training ter-integrasi antara engineering management, procurement management, dan construction management. Training ini sangat penting untuk : Cost Estimator, Project Engineer, Lead Engineer, Senior Engineer, Project Manager, Cost Controller, PPC Officer, Finance Officer, Scheduller, Designer, dan Proposal Officer

SASARAN DAN TUJUAN

Sasaran dan tujuan training ini adalah :

1.    Peserta mengetahui eksekusi cost and estimation

2.  Peserta mengetahui study kasus yang terjadi dalam meng-eksekusi project cost and estimation

3.    Peserta mengetahui cost and estimation level

4.    Peserta mengetahui jabaran utuh cost and estimation yang terlibat di EPCI

5.    Peserta mengetahui interface, risk, dan contingency di cost and estimation

6.    Peserta mengetahui pembebanan direct – indirect cost.

Selain tujuan dan manfaat diatas, pelatihan ini juga bertujuan dan bermanfaat antara lain adalah :

1.    Keikutsertaan dalam training ini dapat dijadikan sebagai penambah score (nilai) dalam mengikuti program Sertifikasi Insinyur Profesional,

2.    Pelatihan ini memiliki nilai Pengembangan Keprofesionalan Berkelanjutan (PKB), bagi pemegang Sertifikasi Insinyur Profesional (SIP), sehingga dapat dijadikan sebagai laporan pembelajaran untuk kewajiban Pengembangan Keprofesionalan  Berkelanjutan atau Continuous Professional Development (CPD sebagai persyaratan perpanjangan masa berlakunya sertifikat insinyur profesional tersebut. Nilai PKB untuk pelatihan ini dengan durasi 2 hari atau 16 Jam adalah 15 point

.

PELAKSANAAN DAN PENDAFTARAN

Dilaksanakan pada Sabtu-Minggu, 24-25 November 2018, jam 08.00 - 17.00 bbwi. Tempat penyelenggaraan : Hotel Aksana,  Jl. Bundo Kanduang No. 14-16, Padang Barat, Kota Padang, Sumatera Barat.

PENDAFTARAN PESERTA:

1.    PII Wilayah Sumbar : Telp: 0822-88515243 Up: Iman Satria  E-mail extro_iman@yahoo.com. 081267048896 Up: Iqbal. E-mail: iqbalbatuah@yahoo.com.

2.    Badan Kejuruan Mesin-PII: Jl. Bandung  No. 1, Menteng, Jakarta, Telp. (021) 31904667, Hp: 0813-16716412, Up: Arfi Yesso,  Email: bkmesin_pii@yahoo.co.id dan arfi.yesso@gmail.com.

BIAYA TRAINING

Biaya investasi training : Rp 3.000.000,-/orang (Anggota PII)  Rp. 3.500.000,- (Umum)  dengan fasilitas : materi (hard copy/ soft file), alat tulis, sertifikat, 2 x snack, dan makan siang.

***

Download Brosur dan Formulir Registrasi Peserta
